The Rye Bay 228 is available as Plans, Kits and also Custom Built

Loa: 2.3m (7’ - 6”)
Beam: 1.2m (3’ - 11”)
Draft: 0.14m (0’ - 5.5”)
Dry Weight: 50lb (22kg) - Rowing Spec.
Maximum Load: 500lb (227kg)
Crew: 2 Adults


The "RYE BAY 228" is the Mk IV version of this design as a stitch & tape boat. It is 7' - 6" long with a good 4' beam which makes for a small but spacious boat with an approximate dry weight of 50lb (22kg). It is built in 6mm ply or can be 6mm on the bottom and 4mm sides for a light duty, lightweight boat.
This has been a popular design and was the first of our designs we sold as a complete boat. It has had many uses - as a tender, a work boat, a fishing boat and as a sailing dinghy.
It can take a small outboard motor - 2hp petrol or electric - and has optional built-in buoyancy tanks. The plans now show details for a rowing/motor version and a sailing version.


Basic Materials Required (for complete hull build):

2 x 6mm x 2.44m x 1.22m Plywood - 3kg Epoxy Pack – 2ltr fillet mix – 25m x 100mm FG Tape – 3m x 200mm x 12mm (min) – 18mm (max) Timber for seats, 6 x 2.4m x12mm x 21mm for trim (min size), 100 x 4.8mm x 300mm cable ties.



The Rye Bay 228 is available as

Plans Packages –

Digital Download Plans  - £15   From the download option

A3 Printed Workshop Plans  - £25   A3 drawings with full instruction manual

Full Size Paper Patterns Plans   - £45   Full size paper patterns of the main hull components with full instruction manual



Rye Bay 228 - Options from

SKU: RB228A3
£25.00 Regular Price
£20.00Sale Price
Plans & Options
